ARK-1250L User Manual 20
2. Install the mPCIe/mSATA module.
3. Put the bottom cover back and secure it with the 6 x screws.
2.5.4 M.2 Installation
1. Loosen the 6 x screws on the front/sides and remove the bottom cover.
