9 ECU-1251 Series User Manual
Chapter 2 Hardware Functionality
2.2 LED Status Indicators
The LEDs in the front panel can be divided into 4 groups:
Figure 2.2 ECU-1251 LED status indicator
2.2.1 System Status Indicators:
LED Status Description
PWR
Green Power is on
Off Power is off
IRIG
Green
Customers can define the Programmable LED state accord-
ing to the actual need.
Off
To Next Page
