2.4 Cooling Fan and Filter
There are two (2) Cooling Fans located inside the chassis. The Cooling
Fans are easy maintenance and provide adequate cooling to the system
by blowing air inward. Please refer the Figure 2-5 and Figure 2-6 to
replace the defective fan. Press the location A and then pull the B
which is showed on Figure 2-6 then the connector could be released.
Please refer Figure 2-7 to change the filter if you found the filter was
blocked with dust or other particles
Figure 2-5
A
B
Figure 2-6
IPC-610-H User's Manual
14
