Chapter 1 General Information
1.1 Introduction
IPC-610-H is a 4U height 14-slot rackmount IPC chassis designed for
building mission-critical applications. The unit includes a versatile
14-slot passive-backplane by option (which supports ATX M/B form
factor), a high-efficiency 300W ATX with power factor correction (PFC)
power supply, and dual easy maintenance cooling fan which provides
abundant cooling. A wide range of standard computing peripherals can
be integrated with the chassis to meet different application development
under mission-critical environment 24 hours a day, 7days a week.
1.2 Specifications
General
! Construction: Heavy duty steel chassis
! Drive bay: Shock-proof. Front accessed three 5.25" & one 3.5”
drivers
! Cooling system: Dual easy-to-replace 84 ~ 114 CFM cooling
fan with front-access air filter
! Controls: Power switch (on-off or momentary) and reset switch
behind the lockable door
Indicators
! Power: Green LED shows the power status
! HDD: Green LED for HDD activity
! Voltages: 3.3V/+5V/+12V/-5V/-12V/Vsb single-color LED
(green) shows the voltage status
! Connectors: Front access USB and PS/2 keyboard, rear panel
9-pin connector (9-pin connector is not included for the M/B
version)
! Paint Color: Pantone 414U Gray, textured
! Operating temperature: 0 ~ +40°C (32°F ~ 104°F)
IPC-610-H User's Manual
2
