be moved to the X/Y coordinate positions of the tool alignment instrument, dropped
down to the position of tool alignment starting point Z before the tool alignment
procedure can start.
"Tool alignment instrument's X axis coordinate reference point": sets the machine coordinate of the X axis
above the tool alignment instrument. Press 【XY guide】 for guided input
after the tool is moved to the designated position.
"Tool alignment instrument's Y axis coordinate reference point": sets the machine coordinate of the Y axis
above the tool alignment instrument. Press 【XY guide】 for guided input
after the tool is moved to the designated position.
"Tool alignment starting point Z": sets the machine coordinate for starting tool alignment on the Z axis.
Press【Z axis guide】 for guided input after moving the cursor to this field.
"Lowest machine coordinate of the Z axis": sets the machine coordinate of the lower limit position for tool
alignment on the Z axis. Press【Z axis guide】 for guided input after moving the
cursor to this field.
"Return to Z's safety point after tool alignment": sets the machine coordinate of the point to return to
after completing tool alignment on the A axis. Press【Z axis guide】 for guided
input after moving the cursor to this field.
"Blowing air M": sets the M code for blowing air during tool alignment.
"Shut off air M": sets the M code for shutting down air after tool alignment is completed.
Single tool/multiple workpieces:
"Measurement speed": sets the feed rate (mm/min) during measurement, which is generally between 100
and 300.
"Whether to use a reference point": when 0 is selected (not using a reference point), the tool alignment
procedure will be carried out based on current X/Y coordinates; when 1 is selected (a
reference point is used), Z axis will return to the machine reference point, then it will
be moved to the X/Y coordinate positions of the tool alignment instrument, dropped
down to the position of tool alignment starting point Z before the tool alignment
procedure can start.
"Tool alignment instrument's X axis coordinate reference point": sets the machine coordinate of the X axis
above the tool alignment instrument. Press 【XY guide】 for guided input
after the tool is moved to the designated position.
"Tool alignment instrument's Y axis coordinate reference point": sets the machine coordinate of the Y axis
above the tool alignment instrument. Press 【XY guide】 for guided input
after the tool is moved to the designated position.
"Tool alignment starting point Z": sets the machine coordinate for starting tool alignment on the Z axis.
Press【Z axis guide】 for guided input after moving the cursor to this field.
