Advantech MIO-5251 - Page 57

MIO-5251 User Manual 48
CN15 Mini PCIE
Part Number 1654002538
Footprint FOX_AS0B226-S68K7F
Description MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H
Pin Pin Name
1 WAKE#
2 +3.3VSB
3NC
4GND
5NC
6 +1.5V
7NC
8UIM_PWR
9GND
10 UIM_DATA
11 REFCLK-
12 UIM_CLK
13 REFCLK+
14 UIM_RESET
15 GND
16 UIM_VPP
17 NC
18 GND
19 NC
20 W_DISABLE#
21 GND
22 PERST#
23 PERn0
24 +3.3VSB
25 PERp0
26 GND
27 GND
28 +1.5V
29 GND
30 SMB_CLK
31 PETn0
32 SMB_DAT
33 PETp0
34 GND
35 GND
36 USB D-
37 GND
38 USB D+
39 +3.3VSB
40 GND
41 +3.3VSB
