MIO-5251 User Manual 50
25 B-
26 GND
27 GND
28 +1.5V
29 GND
30 SMB_CLK
31 A-
32 SMB_DAT
33 A+
34 GND
35 GND
36 USB D-
37 GND
38 USB D+
39 +3.3V
40 GND
41 +3.3V
42 NC
43 NC
44 NC
45 NC
46 NC
47 NC
48 +1.5V
49 NC
50 GND
51 NC
52 +3.3V
