51 PCM-3365 User Manual
Appendix A Pin Assignments
18 GND
19 NC
20 WIFI1_DISABLE#
21 GND
22 PLTRST#
23 mSATA_mPCIE_RX-
24 +V3.3SB
25 mSATA_mPCIE_RX+
26 GND
27 GND
28 +V1.5
29 GND
30 SMB_STB_CLK
31 mSATA_mPCIE_TX-
32 SMB_STB_DAT
33 mSATA_mPCIE_TX+
34 GND
35 GND
36 USB D-
37 GND
38 USB D+
39 +V3.3SB
40 GND
41 +V3.3SB
42 CLKOUT_a_LPC0
43 GND
44 LPC_a_FRAME#
45 LPC_a_AD0
46 NC
47 LPC_a_AD1
48 +V1.5
49 LPC_a_AD2
50 GND
51 LPC_a_AD3
52 +V3.3SB
