UTC-318 User Manual 50
Table A.25: CN22(D),CN15(E),CN16(FG),CN168(H):SPEAKER
Part Number 1655304020
Footprint WF_4P_79_BOX_R1_D
Description WAFER BOX 2.0mm 4P 180D(M) W/LOCK A2001WV2-4P
Pin Pin name
1 AUD_OUTA-
2 AUD_OUTA+
3 AUD_OUTB+
4 AUD_OUTB-
Table A.26: M.2_1(G):M.2_2230
Part Number 1654012663-01
Footprint NGFF_75P_APCI0163-P001A
Description NGFF 75P 0.5mm 90D(F) H=8.5mm SMD APCI0163-P001A
Pin Pin name
1,7,33,39,45,51 GND
18,57,63,69,75 GND
3 USB_D+
2,4,72,74 3.3V
5 USB_D-
35 PCIE_TX+
37 PCIE_TX-
41 PCIE_RX-
43 PCIE_RX+
47 CLK_100M+
49 CLK_100M-
55 PCIE_WAKE#
9,11,13,15,17,19,21,23 NC
61,63,65,67,71,73 NC
6,8,10,12,14,16,20,22 NC
32,34,36,38,40,42,44 NC
46,48,58,60,62,64,66 NC
68,70 NC
