41
UTC-320 User Manual
Appendix A
I/O Pin
Assignments
T
able A.18: CN19:External USB
Part Number
1654010969-
01
Footprint
USB_9x2P_UEA1
1
12C-8HS6-4F
Description
USB CONN. 18P 2.0mm 90D(F) DIP UEA1
1
12C
Pin
Pin name
1+
5
V
S
B
2D
-
3D
+
4G
N
D
5
SSRX-
6
SSRX+
7G
N
D
8
SSTX-
9
SSTX+
10
+5VSB
11
D
-
12
D+
13
GND
14
SSRX-
15
SSRX+
16
GND
17
SSTX-
18
SSTX+
