Frame Data Parser for WISE LoRa modules v1.3.7
24
Advantech Co., Ltd., Copyright 2020
16
PT100(392) -200~ +600℃
17
PT1000 -40~ +160℃
status
Object
Low Alarm Status
Read 1: low alarm occurred.
0: not occurred
Write 0: clear the low alarm
status
High alarm status
Read 1: high alarm occurred.
0: not occurred
Write 0: clear the high alarm
status
Raw Data
int
AI value is the measurement raw data with
range 0 to 0xFFFF.
Event
int
Bit Order
Description
0
Fail to provide AI value (UART timeout,
ADC error)
1
Over Range
2
Under Range
3
Open Circuit (Burnout)
4
Reserved
5
Unavailable Channel Configuration
(Channel Disabled, DI Mode Used)
