3.1.9 FFT (Fast Fourier Transform)
3.1.9.1 FFT in CSV format
Field Name
Data Type
Description
TIME
Int
FFT Data time.
AXIS_TYPE
String
X, Y, or Z Axis.
DATA
Int
FFT Data value, unit: mg.
LOG_INDEX
Int
(For packet transmission only) Index number
of each FFT data round.
BYTE_OFFSET
Int
Byte offset in one FFT data round. Since each
FFT data round contains 4800 bytes (2400
data), the range of the value is 0 to 4799.
SAMPLE_FREQ
Float
Frequency number of FFT data for each axis
(X,Y,Z).
3.1.9.2 FFT in JSON format
Field Name
Data Type
Description
LOG_INDEX
Int
(For packet transmission only) Index number
of each FFT data round.
TIME
Int
FFT Data time.
SAMPLING_RATE
Int
The average number of samples obtained in
one second.
