NUMBER_OF_SAMPLES
Int
Number of FFT Data samples.
START_BYTE_OFFSET
Int
Start of Byte offset in one FFT data round.
Since each FFT data round contains 4800
bytes (2400 data), the range of the value is 0
to 4799.
END_BYTE_OFFSET
Int
End of Byte offset in one FFT data round.
Since each FFT data round contains 4800
bytes (2400 data), the range of the value is 0
to 4799.
AXIS_DATA
Array Axis
Data
Axis Data Object.
3.1.9.3 FFT Data Re-transmission
Field Name
Data Type
Description
LOG_INDEX
Int
(For packet transmission only) Index number
of each FFT data round.
BYTE_OFFSET
Int
Byte offset in one FFT data round. Since each
FFT data round contains 4800 bytes (2400
data), the range of the value is 0 to 4799.
LENGTH
Int
Length of lost FFT data, unit: byte.
3.1.10 Axis Data
Field Name
Data Type
Description
AXIS_TYPE
String
X, Y, or Z Axis.
