Figure 1
Typical ACM Dryer Components
Coalescing Oil
Filter
Air Filter
0.01 Micron
Solenoid
Valve
Heater Box
Membrane
Dryer
High
Temperature
Switch
Compressed
Air Inlet
Pressure
Switch
Pressure
Gage
Standard Air
Filter
Optional Dust
Collector
