Page 14 ACM Series Dehumidifying Dryers
Figure 4
ACM Series Floor-Mount Dimensions
ACM30 and ACM60 floor-mount dimensions in inches/cm
ACM30 ACM60
Dimension in. cm in. cm
A22 562564
B 12.75 32 12.75 32
C 15.5 39 15.5 39
D28 712871
1-7 Specifying a Drying System
Many variables were considered in the selection of your drying
system, including type of materials, residence time, throughput of
the extruder or injection molding machine. Should your operating
environment change, AEC can advise you on necessary equipment
and process time and temperature modifications required for your
system.
