AEC ACM Series - ACM Series Machine-Mount Dimensions

ACM Series Dehumidifying Dryers Page 13
Figure 3
ACM Series Machine-Mount Dimensions
ACM30 and ACM60 machine-mount dimensions in inches/cm
ACM30 ACM60
1.5 ft.
3
Hopper
(40 liters)
3.0 ft.
3
Hopper
(80 liters)
4.0 ft.
3
Hopper
(120 liters)
3.0 ft.
3
Hopper
(80 liters)
4.0 ft.
3
Hopper
(120 liters)
6.0 ft.
3
Hopper
(160 liters)
Dimension in. cm in. cm in. Cm in. cm in. cm in. cm
A 40 102 40 102 40 102 47 119 47 119 47 119
B 37.5 95 44.5 113 50.5 128 44.5 113 50.5 128 62.5 159
C225622562256256425642564
D287128712871389738973897
Mounting flange
Hopper mounting flanges on 0.75 and
can drill to match existing machine throat.
Diameter hole:
Notes:
and 1.5 cu. ft. (20 & 40 liter) hoppers
are supplied blank so the customer
3.0 cu. ft. (80 liter) hoppers and larger
are not supplied with a cast flange
(
as shown
)
.
E
E
F
C
A
B
D
