AEC R5KL1 - Page 32

Setting Setting
60
61
8.2.5 485 Address
Interface Description
Press UP/DOWN button to adjust the input
figure;
Press ENTER button to confirm or ESC
button to cancel the input and return to setup
interface;
The input value should range between 1 and
64.
8.2.6 485 Baud rate
Interface Description
Press UP/DOWN button to move
corresponding options;
Press ENTER button to confirm or ESC
button to cancel the selection and return to
setup interface;
There are three alternative options:
2400/4800/9600.
8.2.7 Language
Interface Description
Press UP/DOWN button to move
corresponding options;
Press ENTER button to confirm or ESC
button to cancel the selection and return to
setup interface;
--485 ADDRESS--
INPUT： 1
Value ra nge
(1~64 )
--SELECT--
1：2400 bps
2：4800 bps
→3：9600 bps
--LANGUAGE--
→1：CHINESE
2：ENGLISH
8.2.8 LCD backlight
Interface Description
Press UP/DOWN button to adjust the input
figure;
Press ENTER button to confirm or ESC
button to cancel the input and return to
setup interface;
The input value should range between 20
and 120.
8.2.9 Date/time
Interface Description
Press UP/DOWN button to adjust the input
figure;
Press Enter button to move cursor
backward, confirm input and return to
setup interface;
Press ESC button to move cursor forward
and return to setup interface;
The input value should range between 2000
and 2099.
8.2.10 Clear history
Interface Description
Clear all the previous history in
Inquiry/Record menu.
Press UP/DOWN button to move
corresponding options;
Press ENTER button to confirm or ESC
button to cancel the selection and return to
setup interface ;
--LIGHT TIME--
INPUT：20
UNIT：S (seconds)
Value range
(20~120)
--DATE/TIME--
DATE：2018-09-19
TIME：10：01：12
WEEK：Monday
--DEL REC --
→1：CANCEL
2：CONFIRM
