AED IONOMAT 1 - Technical Specifications

IONOMAT 1
Page 13 sur 14
Do not use if damaged
packaging
Alternating current
Catalog Number
Serial number
User Manual
WARNING !
RoHS
Fragile
Do not throw in
household garbage
Keep out of direct
sunlight
Protect from moisture
Displays the
temperature limit
between which the
IONOMAT can be
safely exposed
IP 21
Protection sign
Connection to Class II
Power System
13.7 Technical Specifications
• Dimension of the generator: 220 x 155 x 70mm
• Generator weight: 0.8 kg
• Constant current generator
• Guaranteed current from 0mA to 25mA on a load of 2.2kohms
• Digital reading of current in mA and indication of polarity
• Residual ripple for 10mA 10mV nominal, warranty below 20mV
• 15 s +/- 1 current-delaying device at start-up
• Slow ((1-exponential) growth of the current to reach the preset value
• Automatic zero reversal
• Automatic shutdown, power cancellation and ringing at the end of the cycle
• Casing, buttons made of insulating material
