Noise Level (4m) LpA dB (A) 82
Noise Level (7m) LpA dB (A) 77
Noise Level LwA dB (A) 102
RCD
Voltage (V)
240
Fault Current Rating (A) 25
Trip Current Rating (mA) 30
Trip Time Rating (s) 0.05
If any of the labels come off the unit or become hard to read,
contact the authorised service centre for replacement.
FEATURES
KNOW YOUR GENERATOR
See Figure 3.
The safe use of this product requires an understanding of the
information on the product and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarise yourself with all operating
features and safety rules.
AC CIRCUIT BREAKER
The circuit breaker is provided to protect the generator against
electrical overload and can be used to turn the generator’s
electrical power on or off.
AIR FILTER
The air filter helps to limit the amount of dirt and dust drawn into
the unit during operation.
CHOKE LEVER
The choke lever is used when starting the engine.
ENGINE SWITCH
The engine switch is used in combination with the recoil starter
grip to start the generator. It is also used to turn the generator
off.
FUEL TANK
30 litres
FUEL VALVE
The flow of fuel through the generator is controlled by the
position of the fuel valve.
GROUND TERMINAL
The ground terminal is used to assist in properly grounding
the generator to help protect against electrical shock. Consult
with a local electrician for grounding requirements in your area.
OIL LIGHT
The oil light is an indicator for the oil level. When the oil level is
too low, the oil light will flash in red.
OIL DRAINAGE BOLT
When changing the engine oil, the oil drainage bolt is loosened
to allow old engine oil to be drained.
OIL CAP/DIPSTICK
Remove the oil fill cap to check and add oil to the generator
when necessary.
*DUDJH'RRU2SHQHUí+3 875 2350
Hair Dryer 1250 1250
DIY/Job Site
Quartz Halogen Work Light 1000 1000
$LUOHVV6SUD\HUí+3 600 1200
Reciprocating Saw 960 1400
(OHFWULF'ULOOí+3 600 900
&LUFXODU6DZíLQ 1400 2300
0LWUH6DZíLQ 1800 2900
3ODQHU-RLQWHUíLQ 1800 1800
7DEOH6DZ5DGLDO$UP6DZíLQ 2000 3000
$LU&RPSUHVVRUí+3 1600 4500
*Wattages listed are approximate. Check tool or appliance for actual wattage.
SPECIFICATIONS
Generator
Product Weight (kg) 115
Product dimensions
Width (mm) 800
Length (mm) 800
Height - Length-folded (mm) 700
Height - Length-open (mm) 1350
AC output
AC Frequency (Hz) 50
AC Output Voltage (V) 240
Rated AC Output (W) 5,200
Rated Current (A) 21.67
Circuit Breaker (A) 25
Power Factor 1.0
DC output
Volts 12
Amps 8.3
12V DC Circuit Breaker Circuit (A) 9.2
Engine
Engine Number Yamaha MZ360
Engine Type 4-Stroke; air-cooled
OHV; unleaded fuel
Bore x Stroke 85 x 63
Displacement (cc) 357
Starting System DC Start or Recoil
Fuel Type Regular unleaded fuel
Lubrication Oil SAE 10W-30
Engine Oil Volume (l) 1.1
Fuel Tank Capacity (l) 30
Full Load (h) 9
Half Load (h) 13
Uncertainty dB 2
