AEG QUICK INSTALLATION GUIDE | HYBRID INVERTER SERIES AS-ICH02-2/HV VERSION: PD202208 V1-1-22 4
2
AEG HYBRID INVERTER QUICK INSTALLATION GUIDE SERIES AS-ICH02-2 | VERSION: PD202208 V1-1-22
Product:
1. Do not apply mechanical load to the terminals, otherwise the terminals can be damaged.
2. All labels and warning marks should be visible after the installation. Do not scrawl, damage,
or cover any label on the device.
3.
Do not touch the running equipment to avoid being hurt as its temperature may exceed 60°C. Do not install the equipment at a
place within children’s reach.
4. Unauthorized dismantling or modification may damage the equipment, the damage is not
covered under the warranty.
5. Do not start the BACK-UP function if the inverter is not connected to the battery.
6. If there is any radio or wireless communication equipment below 30MHz near the inverter, you have to:
-Install the inverter at least 30m far away from the wireless equipment.
-Add a low pass EMI filter or a multi winding ferrite core to the DC input cable or AC output cable of the inverter.
7. Warning labels on the inverter are as follows.
HIGH VOLTAGE HAZARD.
Disconnect all incoming power and turn
off the product before working on it.
Delayed discharge. Wait 5 minutes after power
off until the components are completely
discharged.
Read through the guide before
working on this device.
Potential risks exist. Wear proper PPE before
any operations.
High-temperature hazard. Do not touch
the product under operation to avoid
being burnt.
Grounding point. Indicates the position for
connecting the PE cable.
CE marking
Do not dispose of the inverter as
household waste.Discard the product in
compliance with local
laws and regulations, or send it back to the
manufacturer.
1.3 Check before power-on
№
C
C
h
h
e
e
c
c
k
k
i
i
t
t
e
e
m
m
1

The product is firmly installed at a clean place that is well-ventilated and easy-to- operate.
2

The PE, DC input, AC output, and communication cables are connected correctly and securely.
3

Cable ties are intact, routed properly and evenly.
4

Unused ports and terminals are sealed.
5

The voltage and frequency at the connection point meet the inverter grid connection requirements.
