57Cleaning and care
5. Hold the upper edge of the door glass and
take it out of the guide by pulling it
upwards.
6. Tip the water collecting channel towards
the door glass and lift upwards to remove
from the guide.
Cleaning the door glass and the water collecting channel
Clean the door glass panels and the water collecting channel thoroughly with a
solution of water and washing-up liquid. Then dry them carefully.
Inserting door glass panels and the water collecting channel
1. Insert the snap-in hook of the water
collecting channel sideways into the guide.
Apply some pressure from above to snap in
hook on the other side.
2. From above, insert the door glass at an an-
gle into the door profile at the bottom
edge of the door and lower it.
