Cleaning and care56
Oven door glass and water collecting channel
The oven door is fitted with three panels of glass mounted one behind the other
and a water collecting channel. The inner panels and the water collecting chan-
nel can be removed for cleaning.
1 Important! Rough handling, especially around the edges of the front panel, can
cause the glass to break.
Removing the door glass and water collecting channel
1. Open the oven door as far as it will go.
2. Undo the clamping levers (A) on both
door hinges fully.
3. Close the oven door as far as the first posi-
tion (approx. 45°).
4. Take hold of the door trim (B) on the upper
edge of the door at both sides and press in-
wards to release the clip seal. Then remove
the door trim by pulling upwards.
