AEG ELFAMATIC uC 3000 - Test Function

28
P
LCD Button
Button
Note
+
or
–
+
or
–
+
or
–
Important parameters for synchronisation.
AS = Autosynchronisation. The controller synchronises auto-
matically with the charging release if the main release
comes later than defined in the parameter “ S LF ”.
PO = Powertherm charging system. The controller synchronises
automatically with the charging release and, with con-
tinuously applied LF, internally simulates interruption of
the charging release at the 24 hours previously deter-
mined time points for 48 hours.
LF = Synchronisation with the charging release. The controller
synchronises with the charging release signal. If “ LF ” is
selected, the number of hours which have passed since
the charging release must be set in the user menu instead
of the time (during normal operation, the display changes
from UHR/AF to LA/AF).
Time of earliest possible main release.
Caution: If in the case of certain charging models from the
power supply companies an additional release is given very late,
the parameter “
S LF ” must be set to a time after the additional
release, e.g.:
additional release from 21:00 to 23:00 – Set “ S LF ” to at least 22.
The set parameters can be stored so that they can be called up
again after temporary parameter changes.
The set parameters are stored by holding down the
+
button
for longer than 3 seconds. If required, the parameters stored in
this way can be called up again by holding down the
–
button
for longer than 3 seconds.
VR LF LZ KU
ED
SH
SYN
SYNC
AS
VR LF LZ KU
ED
SH
SYN
SLF
VR LF LZ KU
ED
SH
SYN
SAVE
P
P
Manual setup of the controller is now complete. The controller
is ready for operation.
3x
VR LF LZ KU
ED
SH
SYN
14
:
53
14
:
53
M
1.5 Test function
The storage heater can be checked in the TEST menu.
LCD Button
Button
Note
for approx.
3 sec.
2x
VR LF LZ KU
ED
SH
SYN
TEST
M
VR LF LZ KU
ED
SH
SYN
INST
M
TEST menu
+
or
–
Parameters for testing the control line and the charging
controllers in the storage heaters.
AUS = Function disabled
0 % = Control signal for charging suppression is output
100 % = Control signal for full charging is output
3x
VR LF LZ KU
ED
SH
SYN
LDT
AUS
P
For the Fitter
Factory setting:
A reset to the factory setting is made by pressing
the - and + keys in the INST menu simultaneously for more
than 3 seconds.
