The end of the drain hose must always
be ventilated , i.e. the inner diameter of
the drain pipe (min. 38 mm - min. 1.5")
must be larger than the external diameter
of the drain hose.
5.5 Electrical connection
At the end of installation you can connect the
mains plug to the mains socket.
The rating plate and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are compatible
with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any other
appliances may also be in use.
Connect the appliance to an earthed
socket.
The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install this
appliance, contact our Authorised Service
Centre.
The manufacturer does not accept any
responsibility for damage or injury through
failure to comply with the above safety
precaution.
6. CONTROL PANEL
6.1 Control panel description
1
Programme dial
2
Display
3
Startuitstel - Départ Différé touch button
4
Tijd besparen - Gain de temps touch
button
5
Start/Pauze - Départ/Pause touch button
6
Extra touch button
• Vlekken - Taches option
• Voorwas - Prélavage option
• Only rinse option
7
Centrifugeren - Essorage reduction
options touch button
• No Spin option
• Rinse Hold option
8
Temp. touch button
9
Aan /Uit - Marche/Arrêt push button
44 ENGLISH
