h Upgrading SSD
Step 1. If there is a SSD device
installed, unlock the SSD screw and
keep it for later use. Remove the
original SSD deivce.
If the slot is not occupied, nd the
M2X4 screw in the accessory box.
Step 2. Slide the SSD device by the
direction as the gure shows.
Important
Align the notch on the SSD with the
key on the slot and insert the SSD into
the slot.
Step 3. Push down the SSD device
and lock it with the M2X4 screw.
Important
M2X4 screw * 1.
