h Installing Chassis
Step 1. Install the side cover rst.
Keep the lower notchs and the
hooks aligned.
Step 2. Keep the upper notch and
the hook aligned.
Step 3. Slide and push the side
cover back. Then, install the other
side cover as well. Lock the screw.
Important
M3X4 screws * 1.
