AA80 InterVOX Intercom Systems
SM08 Installation and Operation Manual
April 30, 2012 Rev: 5.00 Page 1-3
ENG-FORM: 800-0100.DOTX
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
AA80-060:
6 standard “carbon equivalent” microphones, 250 mVrms for full output,
600 ohm input impedance.
2 Music inputs (1K input impedance) 2.5 Vrms
1 Radio input (1K input impedance) 2.5 Vrms
AA80-062:
6 standard “carbon equivalent” microphones, 250 mVrms for full output,
600 ohm input impedance.
1 Music input (1K input impedance) 2.5 Vrms
1 Radio input (1K input impedance) 2.5 Vrms
1 ICS Key input (ground seeking)
1 ICS Tie Line (for IC expansion)
Outputs: 4 or 6 standard headset outputs (150-600 Ohm)
1 transmitter output (mic/key/ground)
Logic: Pilot priority during transmit.
Music muted during transmit, ICS operations and by incoming radio
audio.
Weight: 0.7 pounds.
End of Section 1.0
