AA80 InterVOX Intercom Systems
SM08 Installation and Operation Manual
April 30, 2012 Rev: 5.00 Page 2-1
ENG-FORM: 805-0100.DOTX
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
Section 2.0 Installation
2.1 General
Installation information in this section consists of unpacking and inspection procedures, installation
procedures, post-installation check, and installation drawings.
2.2 Unpacking and Inspection
Unpack the equipment carefully. Inspect the unit visually for damage due to shipping and report all such
claims immediately to the carrier involved. Note that each unit should have the following:
- AA80 InterVOX Intercom System
- Product Information Card
- Release certification
Verify that all items are present before proceeding and report any shortage immediately to your supplier.
2.2.1 Warranty
All Anodyne Electronics Manufacturing Corp. (AEM) products are warranted for 2 years. See the website
www.aem-corp.com/warranty for complete details.
2.3 Installation Procedures
2.3.1 Warnings
Do not bundle any lines from this unit with transmitter coax line. Do not bundle any lines from this unit
with 400 Hz synchro wiring, or AC power lines.
In all installations, use shielded cable exactly as shown, and ground as indicated
. Significant problems
may result from not following these guidelines.
All audio installations can be severely degraded by incorrect wiring and shielding, and may result in much
higher cross-talk, hum, and ground-loop interference.
2.3.2 Cautions
Do not install an InterVOX unit without making a suitable amendment to the flight manual indicating the
correct operation of the equipment, and effects on other systems.
