AA80 InterVOX Intercom Systems
SM08 Installation and Operation Manual
April 30, 2012 Rev: 5.00 Page 1-2
ENG-FORM: 800-0100.DOTX
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
1.4 Feature and Specification Summary
Input Power: 11-32 Vdc. Typical current 180mA (full o/p) 250mA maximum. May be
battery operated.
Headset Power: Typical 80 mW into each headset (150 Ohm David Clark Headset, or
similar). 4 headsets total, each with short-circuit protection. Total output
power 320 mW typical. 60 mW typical with 6 headsets total.
VOX Operation: Voice band trigger circuit with adjustable threshold on front panel. “Live”
or hot mic operation by rotating VOX control to extreme counter-
clockwise position.
Indicators: Two-color LED indicates: TX – Green
RX (SQ) – Orange
Mounting: Vertical or Horizontal through-panel, or standard clock hole. All plates
included. Optional mounting plate for standard instrument hole.
Controls: Front Panel: ICS Volume
VOX Threshold
Internal: Sidetone (artificial)
RX Volume
Music Level
ATC Muting
Modes: InterVOX All hear the same audio an ICS.
Pilot Isolation Pilot connected directly to the radios,
passengers remain on the ICS and music bus.
Emergency Loss of power puts pilot directly on radio bus.
Inputs: AA80-001:
4 standard “carbon equivalent” microphones, 250 mVrms for full output,
600 ohm input impedance.
2 Music inputs (1K input impedance) 2.5 Vrms
1 Radio input (1K input impedance) 2.5 Vrms
AA80-020:
4 standard “carbon equivalent” microphones, 250 mVrms for full output,
600 ohm input impedance.
1 Music input (1K input impedance) 2.5 Vrms
1 Radio input (1K input impedance) 2.5 Vrms
1 ICS Key input (ground seeking)
1 ICS Tie Line (for IC expansion)
