AEM CD-5 User Manual

6
30-5603 Contents:
· 1 x CD-5GL
· 4 x AV Mount Hardware
(attached to dash)
· 1 x I/O harness
· 1 x power harness
· 1 x USB communication
cable
· 1 x USB bulkhead
extension cable
· 1 x GPS Antenna
· 1 x Velcro
· documentation
Dash Features
· Full color CAN display and logger (logging versions only)
· Completely user definable CAN receive
· Dual CAN bus
· Full graphics display with up to 6 different pages
· Unit ships with 6 display pages for the AEMNet data stream as the default setup
· Completely user definable graphical layouts
· Stand-alone PC program to create and customize layouts
· Water resistant enclosure with rear facing DTM 12 pin connector
· 7" or 5" (diag) 800x480 super bright color display
· Night mode input
· 7 shift lights and 2 alarm LEDs
· 200mb onboard logging memory (logging versions only)
· Up to 1000hz sample rate (logging versions only)
· Onboard 5Hz GPS/GLONASS receiver (GPS versions only)
· Log data downloaded and viewed with AEMdata via USB port with sealed bulkhead extension cable (logging
versions only)
· Beacon input

AEM CD-5 Specifications

General

Brand	AEM
Model	CD-5
Category	Monitor
Language	English
