aerauliqa Quantum NEXT User Manual

10
FUNCTIONALITY DESCRIPTION
CONTROLLER
BUTTON
ICON LED
ACOUSTIC
SIGNAL
Antifrost
Thisfunctionalitypreventsfrostbuildingupontheheatexchangerdue
toextremelycoldair.Whenitisactivated,theunitrunsinextractonlyat
speed 1, for 30 minutes.
fixedred
Acoustic signal
Anytimeasettingis transferredfromthecontrollertotheunit,ashort
acoustic signal is emitted. This can be deactivated by pressing the cgfgf
buttonfor7seconds,afterwhenagreenledashestoindicatethatthe
acoustic signal is off. To reactivate the acoustic signal repeat the same
operation for 7 seconds until the led becomes green and an acoustic signal
is emitted.
green short
BACKUPBUTTON
Incasetheremotecontrollergetslostorthebatteriesaredead,speeds1,3andOFFpositioncanbeselectedfromthe
onboardtouchbutton(Cimagepag.7).Theairowdirectionisalwaysalternateandtheoperationmode(eithercomfortor
efficiency)isthelastselectedfromtheremotecontroller.
SYNCHRONISATIONOFANUMBEROFUNITS
Itispossibletosynchronizedupto10unitscontemporaneously,throughwire(2poletwistedpairtype,max30mlength)
sotohavemodeandinversiontimesynchronized.Whentheunitisswitchedonforthefirsttime,therotationdirectionof
eachunit(clockwiseoranti-clockwise)isautomaticallyestablished.Otherfunctionalitieslikespeed,smarthumiditycontrol
and boost , continue to be controlled independently on each single unit.
Wiring diagram as per Fig. 16B.
2014/35/UELowVoltageDirective(LVD)and2014/30/UE Electromagnetic Compatibility(EMC),in conformity withthe
following standards:
ElectricalSafety
EN60335-1(2012)+A11+A13;EN60335-2-80(2003)+A1+A2
Electromagnetic Compatibility
EN55014-1(2017);EN55014-2(2015);EN61000-3-2(2014);EN61000-3-3(2013).
Maintenancecanbecarriedoutbytheuserasindicatedinpage38.
MAINTENANCE
SPEED LED COLOUR ACOUSTIC SIGNAL
speed 1 single green led short, single
speed 3 double green led short, double
OFF red led long
STANDARD CONFORMITY
