EPIC FULL LCD
Components:
a. Icons - Tank 1, 2, 3
b. Advance (A) Button
c. Icon - Low Battery
d. Symbol - FO2
e. Symbols - AIR TIME
TIME NDC
TIME O2
TIME TAT
TIME SURF
f. Icon - degrees (Temperature)
g. Icon - Daily Alarm, or -
Transmitter Link
h. Mode (M) Button
i. Symbol - PSI or BAR (Pressure)
j. Icon - Descend Arrow
k. Icon - indicates O2BG
l. Bar Graph
m. Icon - Ascend Arrow
n. Select (S) Button
o. Symbol - STOP TIME
DIVE TIME
p. Symbol - NITROX (Mode)
q. Symbol - FT or M (Depth)
r. Light (L) Button
s. Symbol - MAX
i
o
s
b
e
k
j
m
n
q
r
g
d
a
p
Pay special attention to items marked
with this Warning symbol.
f
h
l
c
