AERMEC 2802 - Page 49

INSPY. 1003. 4138305_03
49
KEY
1. OUT Evaporator ø 4"
2. IN Evaporator ø 4"
3. IN Pumps ø 4"
4. IN Desuperheater ø 2"
5. OUT Desuperheater ø 2"
All connections are VICTAULIC supplied
together with joints to weld
2200
3380
102 702
2576
934 506
1940
1536 910
934
835
645
758
366
19.1.4. WATER CONNECTIONS:
ns 1402 - 1602 (A/E)
5
5
4
4
1
3
2
Evaporator water connections version «PA…PK»
Desuperheater water connections
Evaporator water connections version «00»
758 pump G/H/J/K 778 pump A/B/C/D/E/F
