AERMEC 2802 - Carpentry by 5750 10 Fans (MM) NS 2101 - 2401 - 2002 - 2202 - 2352 - 2502 - 2652 - 2802 °°(A;E°°00

INSPY. 1003. 4138305_03
55
19.4. CARPENTRY BY 5750 10 FANS (mm)
NS 2101 - 2401 - 2002 - 2202 - 2352 - 2502 - 2652 - 2802
°°(A/E°°00…PA…PK)
WARNING:
ALWAYS USE ALL THE
PROVIDED EYEBOLTS
FOR THE LIFTING OF
THE UNIT
402
400
550 5501100 1100
2200
2050
5350
5750
400 400
50
100
2450
2200
50
1002000
2100
1915 1915720
1
73 5
8
2
4
6
POSITION OF VIBRATION DAMPERS
POSITION FOR LIFTING
