AERMEC ANL 040 - Page 4

251608. 6755441_02
ANL-ANLH 020-202
EN
ANL050H°
VMF SYSTEM for the CONTROL AND PRODUCTIONS OF DHW ;^^KZ/^ͿЧ
1 E5 (white or black)
2
VMF-ACS3KTN | 6KTN |8KTN
Control of:
- 3 way valve
- Sensor DHW storage tank
- Immersion heater DHW storage tank (for integration and anti-legionella cycle)
3 3 way valve (not supplied)
4
Immersion heater DHW storage tank (not supplied) (for integration and anti-legionella
cycle)
5 Interface board RS485 ;^^KZzDKhͲϰϴϱͿПО
6 DHW storage tank (not supplied)
8 System buffer tank (not supplied)
4.4. ^z^dDyDW>&KZ,tWZKhd/KEt/d,E>ϱϬ,Σt/d,^^KZzsD&ͳ^
M
8
1
2
3
4
5
6
9 For further information refer to the specific
VMF system documentation available on the
website:
www.aermec.com
10 Accessory required for the unit to communi-
cate with the VMF system
