31
L1
L2
L3
N
L1
L2
L3
N
EXAMPLE LAYOUT OF THE ELECTRICAL PANEL  VERSIONS ° / P - Three-phase power supply (400V/3N/50Hz)
Position of electrical panel - versions ° / P
FAN CONDENSER
(only in
COOLING ONLY version )
A
B
B
A
(*) Near the clamps of the board there is an
auxiliary control board (11 poles) connected
to the electrical panel wiring.
TERMINAL BOARD (*)
DCPX
(accessory)
ELECTRONIC CONTROLLER
MODUCONTROL
COMPRESSOR
THERMOMAGNETIC
SWITCH
AUXILIARY
THERMOMAGNETIC
SWITCH
COMPRESSOR
CONTACTOR
MASTER
SWITCH
