English
19
IFCLIJ 1107 - 4528500_04
INDEX
The fan coils are delivered with stan-
dard packaging made up from expan-
ded polystyrene shells and cardboard.
PACKAGING
ATTENTION: the fan coil is connected
to the power supply and a hydraulic cir-
cuit. Operations performed by persons
without the required technical skills can
lead to personal injury to the operator
or damage to the unit and surrounding
environment.
ONLY POWER THE FAN COIL USING
230 VOLT, SINGLE-PHASE VOLTAGE
The fan coil may undergo permanent
damage if different electric power sup-
plies are used.
NEVER USE THE FAN COIL FOR
APPLICATIONS FOR WHICH IT WAS
NOT DESIGNED
Do not use the fan coil in husbandry
applications (e.g. incubation).
AIR THE ROOM
Periodically air the room in which
the fan coil has been installed; this is
particularly important if the room is
occupied by many people, or if gas
appliances or sources of odours are
present.
ADJUST THE TEMPERATURE
CORRECTLY
Room temperature should be regulated
to ensure maximum comfort to persons
present, particularly in the case of the
elderly, infants and invalids. Prevent
temperature fluctuations between
indoors and outdoors greater than 7 °C
during summer.
If the temperature is too low in the
summer, there is greater energy
consumption.
DIRECT AIR FLOW CORRECTLY
Air delivered by the fan coil should
not be directed directly at people;
even if air temperature is greater than
room temperature, it can cause a cold
sensation and consequently discomfort.
DO NOT USE WATER THAT IS TOO
HOT
When cleaning the fan coil, use cloths or
soft sponges soaked in warm water (no
higher than 40°C). Do not use chemical
products or solvents to clean any part
of the fan coil. Do not spray water on
interior or exterior surfaces of the fan
coil (danger of short circuits).
CLEAN THE FILTER PERIODICALLY
Frequent cleaning of the filter will ensure
more efficient unit operation.
Check whether the filter is very dirty:
if this is the case, repeat the operation
more often.
Use a suction device to remove built up
dust.
After cleaning and drying the filter, fit
it onto the fan coil by following the
removal procedure in reverse order.
EXTRAORDINARY CLEANING
The possibility to remove the fan
augers, which can be inspected (can
only be performed by staff with specific
technical skill) allows to carefully clean
the internal parts. This is a condition
necessary in very busy places or places
that require high hygiene standards.
DURING OPERATION
always leave the filter mounted on the
fan coil during functioning, otherwise
the dust present in the air will dirty the
coil surface.
IT IS NORMAL
During cooling, water vapour may be
present in the flow air of the fan coil.
In the heating mode it might be possible
to hear a slight hiss around the fan
coil. Sometimes the fan coil might
give off unpleasant smells due to the
accumulation of substances present in
the environment air (especially if the
room is not ventilated regularly, clean
the filter more often).
During functioning, noises and creaks
may be heard inside the device, due
to the various heat expansions of the
elements (plastic and metal), but this
does not indicate any malfunctioning
and does not cause damage to the
unit unless the maximum input water
temperature is exceeded.
FUNCTIONING ANOMALIES
In the case of functioning anomalies,
remove the voltage from the unit
and then re-apply it and re-start the
appliance. If the problem persists, call
the Area After-sales Service immediately.
DO NOT PULL THE ELECTRIC CABLE
It is very dangerous to pull, step on,
crush or fix the electric power supply
cable using nails or staples.
The damaged cable can cause short
circuits and injury to persons.
DO NOT INTRODUCE OBJECTS INTO
THE AIR VENTS
Do not introduce any type of object into
the air outlet slots.
This could cause injury to persons or
damage the fan.
IMPORTANT INFORMATION AND MAINTENANCE
19
20
21
22
23
25
30
71
73
75
Important information • Maintenance • Packaging
Functions
Use
Description • Versions • Functioning limits
Main components • Component description
Installation of the unit
Connections
Installation and replacement of the filter
Dimensions
Wiring diagrams
