COOLING CAPACITY - FCL104
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [w] = Total Cooling capacity
Ps [w] = Sensible Cooling capacity
Qv [m
3
/h] = Air flow rate
NB: the output values in bold type indicate the nominal value.
If sensible output values are above the total output, this means that
cooling is carried out without dehumidification.
If this occurs, take into consideration only the sensible output values.
The Cooling capacity of the table are at maximum speed (maximum
air flow). To determine the Cooling capacity based on the speed
(air flow), the values shown in the table must be multiplied by the
following factors (k):
FCL104
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4
1350 11
Speed V3
1010 0,80 0,79
Speed V2
830 0,68 0,67
Speed V1 (Minimum)
560 0,49 0,47
Tw
[°C]
T [°C]
Ta
W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 5784 4465 5758 5080 5784 5698 5964 5964 6526 6526 6810 6810
17 7462 4442 7447 5069 7432 5687 7417 6303 7395 6914 7402 7221
19 9277 4406 9255 5034 9232 5658 9210 6276 9187 6885 9172 7191
21 11197 4987 11167 5612 11137 6229 11107 6846 11099 7154
23 13251 5549 13236 6180 13191 6794 13176 7103
5
15 4990 4058 5103 4718 5320 5320 5691 5691 6263 6263 6547 6547
17 6765 4094 6750 4719 6728 5334 6758 5965 6833 6593 6908 6908
19 8602 4075 8587 4705 8572 5329 8557 5951 8542 6562 8512 6861
21 10552 4673 10522 5296 10507 5920 10484 6538 10477 6846
23 12636 5252 12606 5874 12576 6493 12561 6801
7
15 4000 3535 4371 4276 4779 4779 5330 5330 5928 5928 6227 6227
17 5753 3609 5743 4231 5835 4882 6021 5562 6268 6240 6433 6433
19 7792 3692 7777 4319 7762 4940 7732 5552 7747 6175 7762 6490
21 9802 4321 9772 4941 9757 5562 9742 6182 9727 6484
23 11916 4916 11901 5544 11871 6161 11856 6468
7
3
15 4490 3813 4552 4443 4799 4799 5371 5371 5938 5938 6217 6217
17 6181 3812 6165 4433 6145 5048 6139 5662 6248 6248 6330 6330
19 7987 3785 7972 4412 7957 5034 7927 5643 7920 6257 7897 6555
21 9907 4372 9877 4992 7927 5643 9832 6225 9824 6532
23 11961 4942 11946 5568 11916 6186 11901 6493
5
15 3706 3397 4031 4031 4500 4500 5093 5093 5675 5675 5959 5959
17 5371 3431 5351 4047 5423 4688 5578 5349 5815 5815 6011 6011
19 7245 3441 7230 4067 7222 4689
7200 5300
7192 5913 7207 6229
21 9202 4049 9187 4675 9172 5294 9142 5903 9135 6209
23 11287 4634 11272 5259 11242 5875 11227 6181
7
15 2887 2887 3474 3474 4103 4103 4727 4727 5330 5330 5629 5629
17 4052 2832 4289 3537 4598 4252 4954 4954 5371 5371 5639 5639
19 6227 2989 6227 3617 6206 4229 6268 4872 6413 5534 6495 5866
21 8347 3672 8332 4294 8317 4909 8302 5523 8302 5832
23 10492 4287 10477 4909 10447 5521 10447 5833
9
3
15 3268 3187 3624 3624 4204 4204 4779 4779 5346 5346 5629 5629
17 4804 3172 4784 3784 4830 4413 4980 4980 5361 5361 5639 5639
19 6623 3164 6608 3786 6593 4402 6572 5011 6557 5620 6567 5932
21 8535 3755 8512 4374 8497 4990 8482 5606 8467 5904
23 10597 4335 10574 4954 10552 5570 10537 5875
5
15 2686 2686 3278 3278 3892 3892 4495 4495 5083 5083 5371 5371
17 3773 2711 3938 3381 4206 4070 4572 4572 5093 5093 5382 5382
19 5763 2791 5753 3410 5743 4026 5773 4654 5887 5298 5969 5625
21 7747 3416 7732 4036 7717 4649 7702 5261 7695 5563
23 9847 4015 9832 4634 9802 5245 9802 5556
7
15 2031 2031 2799 2799 3474 3474 4113 4113 4732 4732 5031 5031
17 2443 2087 3031 2893 3577 3577 4124 4124 4742 4742 5041 5041
19 4392 2222 4423 2850 4598 3523 4866 4224 5186 4924 5361 5279
21 6728 2994 6713 3609 6713 4225 6728 4846 6773 5169
23 8947 3645 8932 4261 8917 4876 8902 5177
