41
IFCLTY 1112 - 4528511_04
Tw
[°C]
T [°C]
Ta
W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 2425 2425 3028 3028 3613 3613 4186 4186 4758 4758 5041 5041
17 3308 2508 3428 3157 3686 3686 4196 4196 4768 4768 5052 5052
19 5145 2530 5134 3147 5124 3756 5129 4375 5237 5009 5299 5299
21 7073 3136 7058 3752 7043 4362 7028 4971 7020 5271
23 9135 3722 9112 4336 9097 4951 9082 5253
5
15 1979 1979 2652 2652 3284 3284 3892 3892 4485 4485 4779 4779
17 2278 2021 2763 2763 3289 3289 3897 3897 4495 4495 4789 4789
19 4062 2089 4072 2707 4196 3358 4428 4037 4732 4719 4902 4902
21 6165 2769 6155 3384 6155 3997 6155 4609 6186 4926
23 8287 3383 8287 4003 8257 4608 8257 4915
7
15 1159 1159 2082 2082 2825 2825 3490 3490 4124 4124 4433 4433
17 1161 1161 2093 2093 2830 2830 3500 3500 4134 4134 4438 4438
19 1917 1246 2649 2102 3201 2884 3711 3638 4211 4211 4469 4469
21 4794 2239 4804 2856 4949 3513 5175 4195 5309 4536
23 7237 2979 7230 3592 7222 4203 7207 4501
13
3
15 1804 1804 2423 2423 3018 3018 3598 3598 4170 4170 4454 4454
17 1948 1876 2428 2428 3026 3026 3603 3603 4181 4181 4464 4464
19 3546 1884 3536 2490 3624 3126 3835 3780 4191 4191 4474 4474
21 5505 2511 5495 3122 5485 3726 5474 4331 5500 4643
23 7567 3105 7560 3720 7537 4324 7530 4626
5
15 1226 1226 2000 2000 2660 2660 3284 3284 3887 3887 4186 4186
17 1231 1231 2002 2002 2665 2665 3289 3289 3897 3897 4196 4196
19 1928 1253 2417 2013 2887 2752 3356 3356 3902 3902 4201 4201
21 4392 2088 4392 2700 4485 3333 4681 3999 4794 4331
23 6608 2746 6593 3352 6578 3956 6578 4260
7
15 585 585 1169 1169 2129 2129 2845 2845 3505 3505 3820 3820
17 585 585 1169 1169 2129 2129 2856 2856 3510 3510 3825 3825
19 604 585 1174 1174 2155 2155 2861 2861 3515 3515 3835 3835
21 2227 1304 2856 2104 3381 2864 3866 3607 4093 3966
23 5217 2246 5217 2853 5320 3494 5402 3822
15
3
15 1153 1153 1807 1807 2417 2417 3008 3008 3583 3583 3871 3871
17 1156 1156 1809 1809 2423 2423 3015 3015 3593 3593 3876 3876
19 1685 1163 2039 1860 2464 2464 3021 3021 3598 3598 3887 3887
21 3794 1868 3784 2468 3845 3093 4016 3739 4134 4063
23 5892 2486 5887 3093 5866 3691 5861 3990
5
15 468 468 1268 1268 2013 2013 2665 2665 3284 3284 3588 3588
17 470 470 1268 1268 2015 2015 2670 2670 3289 3289 3593 3593
19 472 472 1278 1278 2021 2021 2675 2675 3299 3299 3598 3598
21 2113 1265 2567 2000 3010 2725 3454 3434 3680 3680
23 4722 2075 4722 2677 4779 3299 4851 3623
7
15 93 93 585 585 1216 1216 2160 2160 2866 2866 3196 3196
17 93 93 585 585 1216 1216 2165 2165 2871 2871 3201 3201
19 93 93 585 585 1221 1221 2170 2170 2876 2876 3206 3206
21 607 576 1257 1257 2232 2232 2902 2902 3217 3217
23 2505 1334 3082 2102 3577 2842 3814 3207
COOLING CAPACITY - FCL104
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [w] = Total Cooling capacity
Ps [w] = Sensible Cooling capacity
Qv [m
3
/h] = Air flow rate
NB: the output values in bold type indicate the nominal value.
If sensible output values are above the total output, this means that
cooling is carried out without dehumidification.
If this occurs, take into consideration only the sensible output values.
The Cooling capacity of the table are at maximum speed (maximum
air flow). To determine the Cooling capacity based on the speed
(air flow), the values shown in the table must be multiplied by the
following factors (k):
FCL104
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4
1350 11
Speed V3
1010 0,80 0,79
Speed V2
830 0,68 0,67
Speed V1 (Minimum)
560 0,49 0,47
COOLING CAPACITY CORRECTION FACTORS
