AERMEC NLC 0350 - Configurator

22.05  4037360_01 55
22 CONFIGURATOR
Field Description
1,2,3 NLC
4,5,6,7
Size
0280, 0300, 0330, 0350, 0550, 0600, 0650, 0675, 0750, 0800, 0900, 1000,
1100, 1250
8 Operating eld
° Standard mechanic thermostatic valve (1)
X Electronic thermostatic expansion valve (1)
Y Low temperature mechanic thermostatic valve (2)
Z Mechanic thermostatic valve (3)
9 Model
° Cooling only
10 Heat recovery
° Without heat recovery
D With desuperheater (4)
T With total recovery (5)
11 Version
A High eciency
12 Coils
° Copper-aluminium
R Copper pipes-copper ns
S Copper pipes-Tinned copper ns
V Copper pieps-Coated aluminium ns
13 Fans
J Inverter
14 Power supply
6 230V ~ 3 60Hz with magnet circuit breakers
7 460V ~ 3 60Hz with magnet circuit breakers
8 575V ~ 3 60Hz with magnet circuit breakers
9 208V ~ 3 60Hz with magnet circuit breakers
15,16 Integrated hydronic kit
00 Without hydronic kit
Kit with storage tank and pump/s
01 Storage tank with low head pump
02 Storage tank with low head pump + stand-by pump
03 Storage tank with high head pump
04 Storage tank with high head pump + stand-by pump
Kit with pump/s
P1 Single pump low head
P2 Pump low head + stand-by pump
P3 Single pump high head
P4 Pump high head + stand-by pump
(1) Water produced up to 39.2 °F.
(2) Water produced from 32 °F up to 17.6 °F
(3) Water produced from 39.2 °F up to 32 °F
(4) When functioning, the temperature of the water in the heat exchanger inlet must never drop below 95°F. For
“YD” and “ZD” recovery versions, contact the headquarters.
(5) With this option the "Y" and "Z" valvs are not compatible. The units with total recovery are not congurable
with the integrated hydronic kit.
