3. CECK LIST
TOTAL RECOVERY HYDRONIC KIT
NOTE 00 01-03 02-04 P1-P3 P2-P4
REFRIGERANT CIRCUITS
n°2 refrigerant circuit indipendenti ad R410A • • • • • • •
Scroll compressor • • • • • • •
Cycle reversing valve • • • • • • •
High pressure trasducer • • • • • • •
Low pressure trasducer • • • • • • •
High pressure switch • • • • • • •
Low pressure switch - - - - - - -
Source side heat exchanger (Finned pack) • • • • • • •
No-return valves • • • • • • •
Deydrator filter • • • • • • •
Indicator for liquid • • • • • • •
Stafty valve HP branch - - - - - - -
Stafty valve LP branch • • • • • • •
Shut-off valves • • • • • • •
Economiser electronic thermostatic valve • • • • • • •
Economiser • • • • • • •
Solenoid valve • • • • • • •
Thermostatic valve • • • • • • •
System side heat exchanger (plate exchanger) • • • • • • •
Liquid storage tank • • • • • • •
Liquid separators • • • • • • •
Desuperheater (plate exchanger) - • • • • • •
HYDRAULIC CIRCUIT
System side heat exchanger (plate) • • • • • • •
Electrical heater exchanger • • • • • • •
Water filter • • • • • • •
Flow switch • • • • • • •
Pressure switch - - - - - - -
Safety valve - - - • • - -
Air vent valve - - - - - - -
Automatic air vent valve • • • • • • •
Charger plant - - - - - - -
Probe inlet water temperature • • • • • • •
Probe outlet water temperature - - - - - - -
Buffer tank - - - • • - -
n° 1 pump - - - • - • -
n° 2 pumps (n°1 on, n°1 stand-by) - - - - • - •
No-return valves - - - - • - •
Expansion vessel - - - • • • •
Discharge valve • • • • • • •
Recovery side heat exchanger (desuperheater) •
Electrical heater exchanger •
Water filter •
Flow switch -
Pressure switch -
Safety valve -
Air vent valve -
Automatic air vent valve •
Charger plant -
Probe inlet water temperature -
Probe outlet water temperature -
Buffer tank -
n° 1 pump -
n° 2 pumps (n°1 on, n°1 stand-by) -
no-return valves -
Expansion vessel -
Discharge valve •
