fig 1
1
1
2
2
3
3
4
4
5
5
Circuit 1°
Circuit 2°
The drawings are only examples of the
machine hydraulic circuit
KEY
1 Evaporators (plate-type exchangers)
2 Expansion tank
3 Flow switch
4 Pumps
5 Filter
NB
In addition to the filter, victaulic and
welded pipes are provided
The drawings are only examples of the
machine hydraulic circuit
CHILLER HYDRAULIC CIRCUIT DRAIN TAP
(ONLY PUMP VERSIONS)
41
INRLPY. 02.10 4086916_01
