AERMEC NXW0500 - Percentage Distribution of Weights on Supports

20
INXWPY. 1610. 4438880_01
9. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS
9.1. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS VERSION °  SIZE FROM 0500 TO 0750
NOTE
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high head) is negligible.
NOTE
Version with desuperheater (D)
- use the same positions for antivibration pad xing as for the AVX of the standard version
- desuperheater additional weight : 23 kg for all models from 500 to 800 size / 29 kg. for all models from 900 to 1400 size
MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500°
without pump 578 410 832 27% 28% 22% 23% 319
1 pump 680 403 914 33% 33% 17% 17%
320 2 pumps 727 400 985 32% 32% 18% 18%
3 pumps 774 398 1047 31% 30% 19% 19%
4 pumps 822 396 1169 29% 28% 22% 21% 309
NXW0550°
without pump 582 410 829 27% 28% 22% 23% 319
1 pump 684 403 911 33% 33% 17% 17%
320 2 pumps 732 401 982 32% 32% 18% 18%
3 pumps 779 398 1043 31% 31% 19% 19%
4 pumps 826 396 1165 29% 28% 22% 21% 309
NXW0600°
without pump 682 414 900 25% 27% 23% 25% 301
1 pump 784 408 962 32% 33% 17% 18% 320
2 pumps 831 405 1021 31% 31% 19% 19%
309
3 pumps 878 403 1074 30% 30% 20% 20%
4 pumps 926 401 1181 28% 28% 22% 22% 310
NXW0650°
without pump 690 415 899 25% 27% 23% 25% 301
1 pump 796 408 965 31% 33% 17% 18%
309 2 pumps 847 406 1027 31% 31% 19% 19%
3 pumps 897 403 1082 30% 30% 20% 20%
4 pumps 948 401 1189 28% 28% 22% 22% 310
NXW0700°
without pump 727 417 915 24% 26% 24% 26% 301
1 pump 833 411 1043 30% 32% 19% 20%
309 2 pumps 883 408 1097 29% 30% 20% 21%
3 pumps 934 405 1146 28% 29% 21% 22%
4 pumps 984 403 1190 28% 28% 22% 22% 310
NXW0750°
without pump 882 419 1082 24% 26% 24% 26% 303
1 pump 997 413 1212 29% 31% 19% 21%
312
2 pumps 1058 410 1273 28% 30% 21% 22%
3 pumps 1118 408 1327 27% 28% 22% 22%
4 pumps 1159 406 1360 27% 28% 22% 23%
