TECHNICAL DATA
Model TS
13
TS
16
TS
23
TS
34
TS
36
TS
43
TS
46
TS
53
TS
56
TS
63
TS
63
5V
TS
74
TS
74
5V
TS
76
TS
76
5V
Cooling
Total cooling capacity kW 4.85 5.80 7.90 9.60 10.50 11.10 13.30 13.90 16.50 16.60 16.60 21.90 21.90 24.80 24.80
Sensible cooling capacity kW 3.75 4.45 6.40 7.60 8.30 8.95 10.70 9.80 11.70 13.10 13.10 17.80 17.80 20.10 20.10
Water side pressure drop kPa 21 9 24 24 16 23 17 32 27 26 26 28 28 26 26
Water fl ow rate l/h 840 1000 1360 1650 1810 1910 2290 2390 2840 2860 2860 3770 3770 4270 4270
Heating
Heating capacity kW 9.80 12.58 15.50 19.70 21.52 21.60 27.49 25.90 32.89 35.50 35.50 46.30 46.30 52.06 52.06
Water side pressure drop kPa 12 8 17 20 13 17 13 21 21 20 20 23 23 21 21
Water fl ow rate l/h 840 1080 1330 1690 1850 1860 2360 2230 2830 3050 3050 3980 3980 4480 4480
Common data
Nominal air fl ow rate m
3
/h 930 930 1500 1600 1600 2050 2050 2400 2400 3600 3600 4200 4200 4200 4200
Useful static pressure (1) Pa 90 55 100 85 45 115 80 105 70 120 120 115 115 75 75
TSFA fi lter pressure drop (2) Pa 13 13 11 12 12 13 13 11 11 16 16 25 25 25 25
Coil rows n°. 3 63463636334466
Coil water connections d. G3/4" G1" G3/4" G3/4" G1" G3/4" G1" G3/4" G1" G1" G1" G1" G1" G1¼" G1¼"
Fans n°. 112222222222222
Ventilation speed number n°. 3 33333333353535
Motors n°. 1 11111111111111
Motor maximum power W 90 90 147 147 147 184 184 184 184 420 420 600 600 600 600
Maximum input current A 1 1 1.9 1.9 1.9 2.6 2.6 2.6 2.6 3.9 3.9 5.5 5.5 5.5 5.5
Sound pressure level (3) dB(A) 50 50 51 52 52 55 55 55 55 58 58 58 58 58 58
Performances refer to the following conditions:
(1) Rated capacity (maximum speed) without air fi lter.
(2) Air fi lter (TSFA accessory) at rated capacity.
(3) Sound pressure measured in free fi eld conditions at a frontal
distance of 1,5 m from air inlet side, nominal air fl ow rate.
Cooling:
- inlet air temperature 27 °C D.B. ; 19 °C W.B.
- water inlet temperature 7 °C ; Δt = 5 °C
Heating:
- inlet air temperature 20 °C
- water inlet temperature 70 °C ; Δt = 10 °C
Power supply = 230V ~ 50Hz
