AERMEC TS Series User Manual

35
Español
ITSLJ 1002 - 5964000_04
DIMENSIONES [mm]
B
A
40
E
D
210
G2
G1
C
H
I
F
L
15
90
IN
OUT
SC
TS
Air
Air
P
N
M M
TS 13 - 16
QRM
QR
N
TS 23
TS 34 - 36
TS 43 - 46
TS 53 - 56
TS 63
TS 74 - 76
TSTS
TS 13 16 23 34 36 43 46 53 56 63
635V
74
745V
76
765V
A [mm] 645 1000 1000 1100 1345 1345 1345
B [mm] 296 296 296 325 325 375 375
C [mm] 520 520 520 600 600 600 600
D [mm] 500 860 860 960 1200 1200 1200
E [mm] 40 40 40 40 40 40 40
F [mm] 210 210 210 235 235 260 260
G1 - G2 G 3/4” G 1” G 3/4” G 3/4" G 1” G 3/4” G 1” G 3/4” G 1” G 1” G 1" G 1¼”
H [mm] 30 30 30 30 30 30 30
I [mm] 675 1035 1035 1135 1375 1375 1375
L [mm] 335 335 335 335 335 335 335
M [mm] 321 290 290 307 307 330 330
N [mm] 138 138 138 154 154 240 240
P [mm] - 187 187 171 171 209 209
Q [mm] 130 138 138 157,5 279,5 238 238
R [mm] 194 95 95 157,5 279,5 238 238
S [mm] 141 136 136 144 144 115 115
T [mm] 18 22 22 27 27 20 20
SC Ø [mm] 22 22 22 22 22 22 22
Peso [kg] 25 27 35 38 42 42 46 48 52 56 61 67,5
!
"
Air
amortiguador
de vibraciones
tuerca
arandela
arandela
soporte
tuerca
tuerca
tirante
TS 13 16 23 34 36 43 46 53 56 63
635V
74
745V
76
765V
A [mm] 680 680 1040 1040 1040 1140 1140 1380 1380 1380 1380 1380
B [mm] 335 335 335 335 335 335 335 335 335 355 335 335
