IVEDITI 1707 - 4880981_01
030I 040I 130I 140I 230I 240I 330I 340I
RDA000V • •
RDA100V • •
RDA200V • •
RDA300V • •
RPA000V • •
RPA100V • •
RPA200V • •
RPA300V • •
RDAC000V • •
RDAC100V • •
RDAC200V • •
RDAC300V • •
PA000V • •
PA100V • •
PA200V • •
PA300V • •
• •
• •
• •
• •
• •
• •
• •
• •
• •
• •
• •
• •
• • • • • •
BV030 •
BV130 •
BV230 •
BV162 •
KFV10 • • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
030I 040I 130I 140I 230I 240I 330I 340I
TPF • • • • • • • •
SWA • • • • • • • •
KTLP • • • • • • • •
PX • • • • • • • •
PX2 - PX2C6 • • • • • • • •
PXAR • • • • • • • •
PXAE • • • • • • • •
• • • • • • • •
• • • • • • • •
• • • • • • • •
SW3 • • • • • • • •
SIT3 • • • • • • • •
SIT5 • • • • • • • •
VCF43-4324 • • • • • • • •
VCF45-4524 • • • •
VCFD3-324 • • • • • • • •
VCFD4-424 • • • •
VCF3X4R • • • • • • • •
VCF3X4L • • • • • • • •
• • • • • • • •
BC4
• • • • • • • •
BC6 • • • • • • • •
• • • • • • • •
DSC4 • • • • • • • •
GA22 • •
GA32 • •
GA42 • •
GA62 • •
GAF22 • •
GAF32 • •
GAF42 • •
GAF62 • •
• •
• •
• •
• •
SE20X • •
SE30X • •
SE40X • •
• •
• • • • • •
• •
DUCTING ACCESSORIES
• RDA_V: Straight intake connection with rectangu-
lar flange.
• RDAC_V: Straight intake connection with circular
flanges.
• RPA_V: Intake plenum with rectangular flange.
• : Straight discharge with circular flanges.
Internally insulated.
• PA_V: Intake plenum with circular flanges.
Flanges in plastic material.
• : Discharge plenum with rectangular
flange. Internally insulated.
• : Discharge plenum with circular flanges.
Internally insulated. Flanges in plastic material.
•
• KFV10: Circular flanges kit for intake/discharge
plenum.
• GA: Intake grille with fixed louvres.
• GAF: Intake grille with fixed louvres with filter.
• : Discharge grille with adjustable louvres.
• SE: External air damper with manual control.
INSTALLATION ACCESSORIES
• : Hanging kit.
• BC: auxiliary condensate drain tray.
• DSC4: Condensate pump to overcome lifts.
• : Feet for recessed installation.
HEATING ONLY COIL
• BV: 1 row heating only coil.
WATER VALVES
• VCF43 / 4324: Kit composed of 3-way motorised
valve with insulating casing, connections and
insulated copper tubes.
• VCFD3 / 324: Kit composed of 2-way motorised
valve with insulating casing, connections and
insulated copper tubes.
• VCF45 / 4543: Kit composed of 3-way motorised
valve, with connections and insulated copper
tubes.
• VCFD4 / 424: Kit composed of 2-way motorised
valve, with connections and insulated copper
tubes.
• VCF3X4: Valve kit for 4 pipe systems and fan coil
Kit composed of special 3 way motorised valve
copper tubes.
Version VCF3X4L for left hand connection fan
coils.
coils.
Power supply 230V ~ 50Hz.
CONTROL PANELS
The complete characteristics of the control panels
are described in the dedicated files.
Some control panels require combination with
other accessories; consult the relevant documen-
tation.
• SIT 3 - 5: Thermostat Interface Boards. Allows
SIT3: Controls the 3 speeds of the fan and must be
installed on each fan coil unit on the network;
receives controls from the switch or the SIT5
board.
SIT5: Thermostat interface board. Allows a network
PXAE.
• SW3: Water temperature sensor for control
panel PXAE.
• SWA: Air and water temperature sensor for con-
trol panel FMT21.
: The complete characteristics of the
VMF system are described in the dedicated files.
Some VMF components require combination with
other accessories; consult the relevant documen-
tation.
