AERMEC WWB 0330 - MINIMUM TECHNICAL SPACES

15
MINIMUM TECHNICAL SPACES
WWB °  STANDARD OPENING ELECTRICAL PANEL LH
WWB R  REVERSE OPENING ELECTRICAL PANEL RH
A1
A
C
B
B1
B2
C1
C2
A1
A
C
B
B1
B2
C1
C2
WWB
A1 in 19.7
B1 in 3.9
B2 in 39.4
C1 in 31.5
C2 in 3.9
WWB
A1 in 19.7
B1 in 3.9
B2 in 39.4
C1 in 31.5
C2 in 3.9
Minimum technical spaces
Minimum technical spaces
