AERMEC WWM 0500 - Page 25

25
CONFIGURATION 5.1:
STACK IN LINE BACK TO BACK DOUBLE
CONFIGURATION 5.2:
STACK IN LINE BACK TO BACK DOUBLE
CONFIGURATION 5.3:
STACK IN LINE BACK TO BACK DOUBLE
EASY MAINTENANCE
PULL OUT
COOLING CIRCUIT
HYDRONIC CIRCUIT
FEATURES
WWM units n° x9
Multichiller_EVO n° x1
Cooling capacity
ton
245.7
mm in
A 2,600 102.4
B 3,990 157.2
C 2,300 90.6
FEATURES
WWM units n° x36
Multichiller_EVO n° x4
Cooling capacity ton 982.7
mm in
A 2,600 102.4
B 11,970 471.6
C 2,300 90.6
FEATURES
WWM units n° x18
Multichiller_EVO n° x2
Cooling capacity
ton
491.3
mm in
A 2,600 102.4
B 6,650 262.0
C 2,300 90.6
