INSTALLATION AND OPERATION MANUAL

Models SPCA Series Single Stage

Horsepower Range: 1 - 2 H.P.

60 Cycle

Single and Three Phase Installations

Owner’s Record

Pump Model:

Pump Serial No.:

Pump Date Code:

Motor H.P. Voltage Phase

Date of Installation:

Owner:

Installer:

Installer Phone Number:

AERMOTOR

293 Wright St., Delavan, WI 53115

©2005 AE30 (Rev. 7/15/05)

Distribuidora Drago-DSM

Questions and Answers

R
Robin StevensAug 5, 2025
What to do if my aermotor SPCA Water Pump motor will not run?
- D
  Diana HowellAug 5, 2025
  If the Aermotor Water Pump motor won't run, first ensure the disconnect switch is on. If that's not the issue, check the fuse and replace it if it's blown. Also, the starting switch might be defective and need replacement. Finally, inspect the wires at the motor; refer to the wiring instructions to check if they are loose, disconnected, or incorrectly wired, and tighten them if needed.
A
Amy JamesAug 21, 2025
Why does my aermotor SPCA motor run hot and overload kicks off?
- S
  Shaun PetersAug 21, 2025
  If the Aermotor Water Pump motor runs hot and the overload kicks off, it could be due to incorrect wiring. Refer to the wiring instructions to ensure it's properly connected. Also, low voltage can cause this issue, so check with your power company. If the wire size is too small, install heavier wiring.
M
Michelle SilvaAug 28, 2025
How to improve water delivery capacity of my aermotor SPCA Water Pump?
- C
  Christopher PayneAug 28, 2025
  If the Aermotor Water Pump does not deliver water to full capacity, it might be because the water level in the well is lower than estimated; a deep well jet pump may be needed if the water level is over 20 ft. Also, steel piping, if used, could be corroded or limed, causing excess friction; replace it with plastic pipe where possible, or with new steel pipe. Finally, the suction piping might be too small; use larger suction piping.
W
wagnerdianaNov 11, 2025
What to do if my aermotor SPCA Water Pump motor runs but no water is delivered?
- J
  joshuawestNov 11, 2025
  If the Aermotor Water Pump motor runs but no water is delivered, consider the following: 1. If it's a new installation, re-prime the pump according to the instructions. 2. Check all connections on the suction line for air leaks. 3. Replace the foot valve if it's leaking. 4. If the pump has lost prime, check all connections on the suction line and shaft seal. 5. Ensure the water level is not below the suction of the pump; lower the suction line into the water and re-prime. Note that if the water level in the well exceeds the suction lift, a deep well pump is needed. 6. Clean the impeller if it's plugged; refer to the maintenance section. 7. Replace the check valve or foot valve if it's stuck in the closed position. 8. Thaw the pipes if they're frozen, bury them below the frost line...

Summary

Safety Instructions

Electrical Safety

Covers electrical hazards and proper wiring procedures for pump installation.

General Safety

Provides essential safety guidelines for operating and maintaining the pump and surrounding area.

Well Pipe Installation

Cased Well Installation

Instructions for installing piping in cased wells, including foot valve placement.

Driven Point Installation

Guidance for connecting suction pipe to a driven point well system.

Pump;Piping Installation

Pump Installation

Steps and considerations for mounting the pump securely on a foundation.

Horizontal Piping from Well to Pump

Guidelines for suction pipe sizing and priming aids for horizontal runs.

Discharge Pipe Sizes

Recommendations for upsizing discharge pipe based on run length to reduce friction.

Lawn Sprinkling Application

Details the pump's intended use for lawn sprinkling and limitations.

Electrical Installation

Wiring

Instructions for grounding, connecting power supply, and ensuring correct voltage for motor wiring.

Motor Voltage Setting

Operation

Priming the Pump

Detailed steps for filling the pump and suction pipe with water before starting.

Maintenance

Pump Disassembly

Steps to disconnect power and disassemble the pump for maintenance or repair.

Cleaning;Replacing Impeller

Procedure for accessing and replacing the pump's impeller.

Seal Replacement

Removing Old Seal

Instructions on how to safely remove the old shaft seal from the pump.

Installing New Seal

Step-by-step guide for correctly installing a new shaft seal assembly.

Pump Reassembly

Troubleshooting Chart

Limited Warranty

Parts List

aermotor SPCA Series Specifications

General

Series	SPCA
Category	Water Pump
Type	Centrifugal
Application	Agricultural, Industrial
Power Source	Electric
