Subject to Export Control, see Cover Page for details. Page 5
Nov 1/16
SPECIFICATIONS
Input Power (Test Set):
Input Range: 11 to 32 Vdc
Power Consumption: 55 W Maximum
16 W Nominal at 18 Vdc with Charged Battery
Fuse Requirements: 5 A, 32 Vdc, Type F
Input Power (External AC to DC Converter):
Input Range: 100 to 250 VAC, 1.5 A Maximum, 47 to 63 Hz
Main Supply Voltage Fluctuations: ≤ 10% of the nominal voltage
Transient Overvoltages: According to Installation Category II
Environmental (Test Set):
Use: Pollution Degree 2
Altitude: ≤ 4800 meters
Operating Temperature: -20° C to 55° C
(Battery Charging temperature range is 5° Cto 40° C,
controlled by internal charger)
Storage Temperature: -30° to 70° C
(Li Ion Battery must be removed when <-20° C and
>60° C)
Relative Humidity:
5° C to 30° C: 95%
30° C to 40° C: 75%
40° C to 55° C: 45%
Environmental (External AC to DC Converter):
Use: Indoors
Altitude: ≤ 10,000 meters
Temperature:
Operating: 0° C to 40° C
Storage: -20° C to 71° C
